ELECTRODES, FLAT WITH BINDING POSTS CARBON

Item 3151-22

$2.13

This Carbon Electrode Rod is used for electrolysis of reactive materials like hydrochloric acid and other compounds. It is a suitable alternative to platinum. Alligator clips can be used for making wire connections.
• 9″ (230 mm) L x 0.19″ (5 mm) Dia.

Item 3151-41

$0.40

This holder is for using D flash light cell as a small, low-voltage power source in the science laboratory, for kits, etc. It is a snap-fit aluminum holder for 1.33″ (33 mm) Dia. dry cells with Fahnstock clips on both sides for external connections; the holder is provided with holes for attaching to a board or panel. Any number of cells can be connected in series or parallel.

Item 3160-01

$1.36

Use this receptacle for flash lamp bulbs. It consists of a rolled shell of brass mounted in a plastic base with 2 screw terminal connections.
• For use at voltages up to 50 V AC
• 1.38″ (29 mm) Dia. and height 0.63″ (16 mm) H

Item 3161-01

$0.56

Fahnestock Clip

Item 3162-02

$0.15

This magnet is a model of the lifting magnet used in industry, such as for a scrap metal lifter. It consists of 2 plastic bobbins wound with enameled copper wire and mounted on each arm of a soft iron U-core. Each of the bobbins is fitted with 2 0.16″ (4 mm) socket binding posts.
• Comes with Teacher’s Guide

Item 3165-01

$8.13

This apparatus is used for demonstrating the relationship between magnetism and the magnetic effect of an electric current flowing in a wire.
• Magnetic needle: 15 cm
• Aluminum frame

Item 3168-00

$13.75

Use this item when changing magnetic flux in electromagnets, electric motors, generators, and transformers.
• 8″ L (200 mm) x 0.19″ thick (5 mm)

Item 3181-01

$1.08

Use this device to demonstrate the phenomenon of thermal convection in liquids caused by temperature variation. It consists of a rectangular-shaped borosilicate glass tube, 6″ (150 mm) W x 8.25″ (150 mm) H, with a funnel-shaped opening at the top for filling liquids. When this tube is filled with water and heated at 1 corner after adding a dye, potassium permanganate crystals, saw dust, or aluminum powder, the movement of colors or particles illustrates the formation of convection currents.
• Comes with a Teacher’s Guide and reproducible Student Handout

Item 3205-00

$7.75

• Teacher's Guide Included
• Handout Included

Use this Air Core Solenoid to provide an external magnetic field where required and to change the rate of magnetic flux passing through a coil. It consists of a plastic spool with windings of insulated copper. It is useful for classroom experiments and demonstrations on magnetic fields.
• Comes with a Teacher’s Guide
• End plates have brass binding posts
• Capacity 10 A when used intermittently and 5 A when used continuously
• RoHS Certified

Item 3172-00

$143.18

This item is also known as a Convection Box or a Ventilation Apparatus. Use it for demonstrating the phenomenon of convection in air and the principle of room ventilation. It consists of an enameled metal box 4″ (100 mm) W x 8″ (200 mm) L x 4″ (100 mm) H, having a sliding glass door and 2 glass chimneys. When the included tea light candle is placed under 1 chimney and a smoldering tape or parchment paper is placed underneath the other chimney, the flow pattern of smoke dramatically illustrates the formation of convection currents. Tape or parchment paper are not supplied.
• Comes with a Teacher’s Guide and reproducible Student Handout
Includes:
• 2 candles

Item 3210-01

$18.63

• Teacher's Guide Included
• Handout Included

Use these electrodes for assembling voltaic cells, electrolysis experiments, etc. They are a useful addition to classrooms and labs.
• Made of copper and stamped with periodic symbol “Cu”
• Approx. 1″ (25 mm) W x 5″ (125 mm)

Item 3151-03

$1.10

This Bulb Holder is a simple but effective tool used to explore series and parallel circuits. 5 bulbs can be arranged in series, parallel, or complex, by adjusting the Bussbars. Replacement bulbs available (4008-38)• Includes 5 bulbs

Item 2118-05

$10.22

This product is comprised of a tinplate box with 3″ (75 mm) sides; the vertical faces of the box are blackened, roughened, varnished, and polished, respectively. The top opening is 1″ (25 mm) Dia. The apparatus is filled with water maintained at boiling point by a low Bunsen flame. A thermopile and a galvanometer can then be used to compare the relative output of radiant heat from each of the 4 faces. Care should be exercised to prevent radiation from reaching the thermopile directly from the flame.
• Comes with a Teacher’s Guide
Includes:
• Rubber stopper
• Alcohol thermometer

Item 3030-11

$17.50

This classic magnet is suitable for many experimental and demonstration needs in general science and physics laboratories. It offers an easy way to show the power of magnetic fields. The magnet is a useful staple for many classes.
• Traditional style
• Chrome-plated and engraved with N and S to indicate north and south poles
• Supplied with soft iron-plated keeper (armature)
• Made from 0.19″ (5 mm) thick and approx. 0.5″ (12 mm) wide steel strips
• Size: 3″ (75 mm)

Item 3102-02

$2.06
